WAFER STYLE ELASTOMER LINED SPRING
LOADED DUAL DISC CHECK VALVE

MODEL CVL


​MODEL CVL

Size Range: 2 - 24 inch

ASME Class: 150

Champion Valves Inc. Wafer Style Elastomer Lined Spring Loaded Dual Disc Check Valves is a
self-operating, spring loaded valve featuring a fully lined elastomer insert that protects the valve body from media flow, ensuring durability and effectiveness with sensitive materials. Available in EPDM (standard), Buna-N, and Viton ® configurations, our Model CVL uses corrosion-resistant 316 Stainless Steel for all internal support hardware.

VALVE FEATURES

Fully lined elastomer insert provides complete isolation of the process media.

Zero fugitive emission design.

Extruding elastomer liner face eliminates the need for flange gaskets.

Plate travel stops are integrally molded to the valve lining.

Optimizes space utilization, simplifies piping, and minimizes installation costs.

STANDARDS

  • ASME B16.5, B16.34, B16.42, and B31.1

  • Designed per API 594 and Tested per API 598

  • MSS-SP-25, MSS-SP-55

  • API 6A and API 6D (as applicable)

  • MSS-SP-61


CONSTRUCTION MATERIALS

Body Material

Ductile Iron

​

​

Liner Material

EPDM (standard)
Buna-N®
Viton®

Disc Material

316 Stainless Steel​

Aluminum Bronze

​

Spring Material

316 Stainless Steel​

​

​

Interested in this valve?

Click below to get a Flow Rate Analysis to evaluate how our Model CVL will assist your system’s performance.
